On the operation of the solenoid valve winding machine for monitoring purposes, is to remove all the factors that are not conducive to the operation of the winding machine, the early detection of faults, so that timely treatment, so as to avoid failure, resulting in significant losses.

1, solenoid valve winding machine temperature monitoring, this we have said in front, here is no longer repeat.

2, solenoid valve winding machine motor load current monitoring.

When the load current of the electromagnetic valve winding machine increases, the copper consumption of the winding coil will increase, so the temperature of the stator windings and stator core will rise.

Winding machine in normal operation load current should not exceed the rated nameplate on the value, when the environment temperature is increased or decreased load current will also be a corresponding increase or decrease.

At the same time, it should also monitor the balance of three-phase current, and the maximum of two phase current is not more than 10%. If there is a difference, then the stator winding may have a short circuit, open circuit, reverse fault or motor phase operation. At this point should be immediately stopped, to identify the reasons, and then use the exclusion of the fault.

The large capacity of the solenoid valve is generally installed in the control device of a current meter, at any time to monitor its current. Winding machine with small capacity not normally installed ammeter, but also often should use clamp current meter.
